POLARO® M/L/XL
12 V spreader for vehicles with a loading bed
High capacity. Optimum range. Perfect control – POLARO® M/L/XL
The POLARO® M, L and XL gritters are ideal for finely dosed dispensing of grit, salt and sand, and fertiliser over large areas. Your vehicle does not need a hydraulic drive or cardan shaft. Simply mount the gritter on a vehicle with a loading bed, 12 V socket, and a sufficient payload, and off you go! The dimensions of the POLARO® M make it ideal for mounting on sweepers, for example.
If you only want to spread sand and grit, we offer a reinforced auger drive as an option. Whatever your spreading material, you can infinitely adjust the spreading width and rate directly on the control panel, and conveniently change the settings while on the move.
The POLARO® M/L/XL offers, including:
- Control console for easy, user-friendly control of all functions from the driver’s seat (as standard)
- Stepless adjustment of the spreading dosage
- Polyurethane hopper with screw conveyor and vibrator with automatic start-up, for a constant material flow
- All metal parts are of stainless steel as standard
- Water-tight cables and gear motors (IP67)
- A transformer is required for 24 V operation
Even more capacity with the (X)XL extension: For an additional payment, POLARO® L and POLARO® XL are available with a hopper extension, which increases its capacity, e.g. for gritting salt, to approx. 750 kg on the POLARO® L and approx. 1000 kg on the POLARO® XL.
Fields
Spread grit up to 6 mm in size
e.g. using POLARO® L on a John Deere Gator
Professional winter service
using POLARO® L on a Piaggio vehicle
Up to 1000 kg road salt capacity
POLARO® XL including container extension
Technical data
| Spreading width: | 0.8 – 6 m |
| Motor power spreading disc: | 100 W |
| Motor power conveyor: | 250 W |
| Fuse: | 30 A |
| Speed range spreading disc: | 40 – 600 rpm |
| Speed range conveyor: | 2 – 54 rpm |
| Operating voltage: | 12 to 15 Volt |
| Operating temperature: | -10 to +70 °C |
| Storage temperature: | -30 to +70 °C |
| Battery cable: | 3 m + 6 m (6,0 mm²) |
| Control cable: | 5 m |
| Protection class: | IP67 |
| Hopper capacity: | 220 l |
| Dimensions (LxWxH): | 1,562 x 1,112 x 1,245 mm |
| Weight: | 140 kg |
| Capacity, salt: | approx. 500 kg |
| Spreading area: | approx. 14,500 m² |
| Hopper capacity: | 380 l |
| Dimensions (LxWxH): | 1,594 x 1,199 x 884 mm |
| Weight: | 140 kg |
| Capacity, salt: | approx. 500 kg |
| Spreading area: | approx. 25,000 m² |
| Hopper capacity: | 550 l |
| Dimensions (LxWxH): | 1,956 x 1,199 x 884 mm |
| Weight: | 155 kg |
| Capacity, salt: | approx. 720 kg |
| Spreading area: | approx. 36,000 m² |
Special features of the POLARO® m/L/XL
User-friendly operation with the POLARO® M/L/XL control panel
As well as infinitely adjusting the speed of the spreading disc to set the working width, you can also control all other functions centrally via the control panel, such as:
- Altering the screw speed to control the discharge rate, and boost function for briefly discharging larger quantities of spreading material when necessary (ice formation)
- Three memory keys (P1–3) for individual settings
- Automatic breakaway for screw conveyor
- Empty warning, residue emptying, service prompts, etc.
The materials are also streets ahead
All materials are designed for the particular challenges of winter work. So not only are all metal parts of stainless steel as standard, but all cables and the individual gear motors are resistant to the ingress of dust and water (IP67). The hopper is made of temperature-resistant polyurethane that is completely impermeable to air and water, damps vibrations, and resists embrittlement.
Adjustable spreading pattern
The spreading disc can be manually positioned slightly more to the left or right, using two set screws. This way, material can be dispensed directly onto the neighbouring pavement or cycle path, for example, in parallel with gritting the road.
Height-adjustable spreading disc
To achieve the desired results regardless of carrier vehicle, the discharge height of the spreading disc (recommended: 0.40 – 0.80 m from the road surface) can be adjusted in the blink of an eye to suit different types of vehicle.
Vibrator with automatic start-up
The screw conveyor transports the material from the hopper to the spreader. If the flow is blocked, the vibrator – provided as standard – starts up automatically, breaking up the material in the hopper when necessary, so that it can continue to flow.
Downloads
Brochure
POLARO® M/L/XL
2 MB
Accessories
Support feets (height-adjustable)
POLARO L/XL hopper extension
Discharge pipe extension
