POLARO®
12 V spreader with manual dosing
POLARO® – perfectly equipped for winter road clearance without special vehicle.
With the POLARO®, you can spread salt, grit, sand, and also fertiliser using virtually any vehicle having a 12 V supply, e.g. a private car, pickup, lorry, wheel loader, mini tractor, quad bike, etc. The frame of the POLARO® already contains all the holes required for mounting. By steplessly adjusting the spreader disc’s rotational speed from the control panel, you can infinitely adjust the spreading width from 0.8 m (footpath) to 6 m (e.g. parking space) while on the move.
The POLARO® offers, including:
- Stepless adjustment of working width from 0.8 – 6.0 m (up to 12 m as an option)
- Operation via LAS control panel from the cab/driver’s seat
- Stepless adjustment of the spreading dosage – manual
- Frame, valve, and spreading disc made from stainless steel as standard
- Cables protected in waterproof junction box
- Autostart separates agglomerated spreading material
- Stainless steel agitator
- 24 V operation is possible using a transformer
- OPTIONAL for hopper sizes 110 l and 170 l: Saline agitator for slow-flowing salt (e.g. very fine, damp salt) available at extra cost.
Fields
Wheel loader for winter service
POLARO® 170 with drawbar coupling, foldable
POLARO® 110 on a Nissan Navara
fitted with suitable pick-up attachment
POLARO® 70 with rear attachment
easily mounted on ATV/Quad when needed
Technical data
| Spreading width: | 0.8 – 6 m |
| Motor power spreading disc: | 60 W |
| Motor power agitator: | 150 W |
| Fuse: | 25 A |
| Speed range spreading disc: | 40 – 600 rpm |
| Speed range agitator: | 54 rpm |
| Power consumption: | When starting, up to 24 A Normal operation up to 13 A |
| Operating voltage: | 12 to 15 Volt |
| Operating temperature: | -10 to +70 °C |
| Storage temperature: | -30 to +70 °C |
| Battery cable 70 l: | 3 m |
| Battery cable 110 to 250 l: | 5 m (4.0 mm²) |
| Control cable 70 l: | 3 m |
| Control cable 110 to 250 l: | 6 m |
| Hopper capacity: | 70 l |
| Hopper capacity: | 490 x 585 x 870 mm |
| Weight: | 29 kg |
| Capacity, salt: | approx. 90 kg |
| Spreading area: | approx. 4,500 m² |
| Hopper capacity: | 110 l |
| Dimensions (LxWxH): | 490 x 585 x 1050 mm |
| Weight: | 38 kg |
| Capacity, salt: | approx. 140 kg |
| Spreading area: | approx. 7,000 m² |
| Hopper capacity: | 170 l |
| Dimensions (LxWxH): | 690 x 610 x 1100 mm |
| Weight: | 42 kg |
| Capacity, salt: | approx. 220 kg |
| Spreading area: | approx. 11,000 m² |
| Hopper capacity: | 250 l |
| Hopper capacity | 785 x 670 x 1230 mm |
| Weight: | 53 kg |
| Capacity, salt: | approx. 325 kg |
| Spreading area: | approx 16,250 m² |
Special features of the POLARO®
LAS control panel as standard.
With the LAS control panel switching functions the spreading disc speed can be infinitely adjusted to define the working width, as well as the switching functions machine ON/Off and shutter On/Off can be actuated.
Manual dosing
On the POLARO®, the flow rate is set manually directly on the machine, using the dosing valve.
Stainless steel agitator
The patented LEHNER agitator system guarantees a continuous flow of free-flowing material.
Downloads
Brochure
POLARO®
2 MB
Accessories
Additional relief roof for POLARO 250
Battery cable with bracket (1x as standard)
LED work light
Brackets
Pick-up bracket, adjustable
Bracket for lawn mower tractor
ATV/quad holder “Rear”
